IMX429 sensor specifications and
compatible M12 lenses & C-mount lenses
IMX429 is a Sony 2/3-inch global-shutter CMOS image sensor in the Pregius global-shutter machine-vision family. Its 1920x1440, 2.8 MP array uses 4.5 um pixels and reaches 90 fps over SLVS, available in color or mono across a 10.80 mm diagonal. Commonlands matches M12 Lenses to its image circle and supplies the calculated horizontal, vertical, and diagonal field of view at each focal length.
IMX429 specifications
| 품번 | IMX429 |
|---|---|
| 제조사 | 소니 |
| 가족 | 프레지우스 |
| 해상도 | 1920x1440 (2.8 MP) |
| 광학 형식 | 2/3" |
| 활성 영역 | 8.64 × 6.48 mm |
| 센서 대각선 길이 | 10.8 mm |
| 픽셀 크기 | 4.5 µm |
| 셔터 | 전 세계 |
| 최대 프레임 속도 | 90fps |
| 인터페이스 | SLVS |
| 컬러 / 흑백 | 컬러 / 흑백 |
Manufacturer datasheet: Sony IMX429 product page
Compatible Commonlands lenses for the IMX429. Field of View calculated with Distortion.
Each field of view below is calculated for the IMX429 active area (8.64 × 6.48 mm) using our MCP server and Field of view calculator. The rectilinear formula FoV = 2 × arctan(dimension ÷ (2 × focal length)) is incorrect for many lenses as it doesn't include distortion. Coverage shows whether the lens image circle covers the 10.8 mm sensor diagonal. Fisheye and f-theta lenses do not follow the rectilinear formula, so their entries link to the product page for the mapped field of view.
Engineering picks for the IMX429
- Best ~30° HFoV: 16mm C-Mount Lens (CIL553) (16 mm, f/2.8). Why: the closest covering option to 30° horizontal, chosen for tight inspection framing and long read ranges. Field of view on the IMX429: 30° H × 23° V (37° diagonal); image circle covers the full sensor; verified 2026-07-02.
- Best ~60° HFoV: 8mm C-Mount Lens (CIL521) (8 mm, f/1.5). Why: the closest covering option to 60° horizontal, chosen for general-purpose machine-vision framing. Field of view on the IMX429: 57° H × 44° V (68° diagonal); image circle covers the full sensor; verified 2026-07-02.
- Best ~120° HFoV: 4.9mm C-Mount Lens (CIL505) (4.9 mm, f/2.2). Why: the closest covering option to 120° horizontal, chosen for wide navigation and room-scale coverage. Field of view on the IMX429: 104° H × 77° V (132° diagonal); image circle covers the full sensor; verified 2026-07-02.
- Compact low-cost pick: Telephoto 50mm M12 Lens (CIL051) (50 mm, f/2.8). Why: the lowest-priced covering M12 barrel ($79). Field of view on the IMX429: 10° H × 7° V (12° diagonal); image circle covers the full sensor; verified 2026-07-02.
Commonlands offers 14 lens options for the IMX429: M12 Lenses and C-Mount Lenses from 1.3 mm to 100 mm focal length, spanning 5° to 192° horizontal field of view on the IMX429 active area.
| 커먼랜즈 렌즈 | 초점 거리 | 마운트 | F# | 수평 시야각 | 수직 시야각 | 대각선 시야각 | 보도 범위 |
|---|---|---|---|---|---|---|---|
| 피쉬아이 1.3mm M12 렌즈 (CIL293) | 1.3 mm | M12 | f/2.2 | 184° | 184° | 184° | 원형 이미지 |
| 2.2mm M12 어안 렌즈 (CIL282) | 2.2 mm | M12 | f/1.8 | 192° | 181° | 192° | 원형 이미지 |
| 4mm C-마운트 렌즈 (CIL529) | 4 mm | C-마운트 | f/2.8 | 98° | 80° | 112° | 표지 |
| 4.9mm C-마운트 렌즈 (CIL505) | 4.9 mm | C-마운트 | f/2.2 | 104° | 77° | 132° | 표지 |
| 8mm C-마운트 렌즈 (CIL521) | 8 mm | C-마운트 | f/1.5 | 57° | 44° | 68° | 표지 |
| 8.5mm C-마운트 렌즈 (CIL508) | 8.5 mm | C-마운트 | f/2.4 | 55° | 42° | 67° | 표지 |
| 12mm C-마운트 렌즈 (CIL552) | 12 mm | C-마운트 | f/2.8 | 40° | 30° | 48° | 표지 |
| 16mm C-마운트 렌즈 (CIL553) | 16 mm | C-마운트 | f/2.8 | 30° | 23° | 37° | 표지 |
| 25mm C-마운트 렌즈 (CIL554) | 25 mm | C-마운트 | f/2.6 | 20° | 15° | 24° | 표지 |
| 35mm C-마운트 렌즈 (CIL555) | 35mm | C-마운트 | f/2.6 | 14° | 11° | 18° | 표지 |
| 50mm M12 망원 렌즈 (CIL051) | 50 mm | M12 | f/2.8 | 10° | 7° | 12° | 표지 |
| 50mm C-마운트 렌즈 (CIL556) | 50 mm | C-마운트 | f/2.8 | 10° | 7° | 12° | 표지 |
| 75mm C-마운트 렌즈 (CIL557) | 75 mm | C-마운트 | f/3 | 7° | 5° | 8° | 표지 |
| 망원 100mm M12 렌즈 (CIL100) | 100 mm | M12 | f/3.6 | 5° | 4° | 6° | 표지 |
How to choose a lens for the IMX429
Start from the field of view your application needs, then read across to the focal length that produces it on the IMX429. Confirm the lens image circle covers the 10.8 mm diagonal so the corners are not cropped, and check the lens resolution is rated for 2.8 MP or higher so it resolves the 4.5 µm pixels. For exact working-distance and object-size numbers, run the figures through the Commonlands field of view calculator.
Sourcing a MIPI camera module around the IMX429? Commonlands can provide customized MIPI modules with our lenses; MoQs apply. Commonlands provides M12 lenses and C-mount optics and ships from San Diego, with same-day shipping for in-stock lenses ordered by 12 PM PST. We also assemble and align lens-to-sensor modules. Talk to an applications engineer.
